ASTM A213 T92 Tubes are advanced chromium-molybdenum-vanadium alloy steel tubes engineered for high-temperature and high-pressure service. They are manufactured according to ASTM A213 / ASME SA213 standards and are primarily used in power plants, refineries, and petrochemical industries. T92 tubes are designed for critical applications such as superheaters, reheaters, and boilers, providing superior strength, thermal fatigue resistance, and oxidation resistance at elevated temperatures compared to earlier T91 and T22 grades..
The chemical composition of T92 tubes includes approximately 9% chromium, 0.5–1% molybdenum, and small additions of vanadium, niobium, and nitrogen, along with carefully controlled carbon, manganese, and silicon. This alloy composition significantly improves creep strength and high-temperature performance, making it ideal for ultra-supercritical steam applications and environments with high thermal stress..
Mechanically, ASTM A213 T92 Tubes offer exceptional tensile and yield strength, excellent hardness, and good elongation. Typical mechanical properties include a minimum yield strength of 620 MPa, tensile strength of 760–950 MPa, and elongation around 20%. These properties ensure that T92 tubes maintain dimensional stability, toughness, and reliability under extreme operating conditions..
Metal Tubular Products is a global stockist and supplier of ASTM A213 T92 Tubes, maintaining extensive inventories in seamless form across various diameters, wall thicknesses, and lengths. Tubes are supplied in random, double-random, or custom cut lengths, with plain or beveled ends, meeting international testing and quality standards such as EN 10204 3.1 / 3.2 Mill Test Certificates.
| Standard | ASTM A213 / ASME SA213 |
|---|---|
| Grade | T92 |
| Material | Chromium-Molybdenum-Vanadium Alloy Steel |
| Product Forms | Seamless Tubes |
| Manufacturing Process | Hot Finished / Cold Drawn |
| Heat Treatment | Normalized & Tempered |
| End Finish | Plain End, Beveled End, Threaded |
| Application | Boilers, Superheaters, Reheaters, Heat Exchangers, Power Plants, Petrochemical Units |
Worldwide, T92 tubes are supplied to thermal power plants, chemical processing units, petrochemical refineries, and other high-pressure systems. Metal Tubular Products ensures timely delivery, technical support, and compliance with global specifications, making them a trusted partner for industrial and energy sector clients..
Selecting ASTM A213 T92 Tubes ensures long service life, safe operation, and reduced maintenance costs in high-temperature and high-pressure applications. Engineers and procurement teams should consider wall thickness, diameter, heat treatment, and certification requirements when specifying T92 tubes. With reliable suppliers like Metal Tubular Products, industries have access to high-quality T92 tubes globally, ready for critical applications..
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 – 0.12 |
| Manganese (Mn) | 0.30 – 0.60 |
| Phosphorus (P) | Max 0.020 |
| Sulfur (S) | Max 0.010 |
| Silicon (Si) | 0.20 – 0.50 |
| Chromium (Cr) | 8.5 – 9.5 |
| Molybdenum (Mo) | 0.50 – 1.05 |
| Vanadium (V) | 0.18 – 0.25 |
| Niobium (Nb) | 0.06 – 0.12 |
| Nitrogen (N) | 0.03 – 0.06 |
| Property | Value |
|---|---|
| Minimum Yield Strength | 620 MPa (90,000 psi) |
| Tensile Strength | 760 – 950 MPa (110,000 – 138,000 psi) |
| Elongation | ≥ 20% |
| Hardness | ≤ 250 HB |
| Outside Diameter (OD) | Wall Thickness | Length |
|---|---|---|
| ½” OD to 5” OD | 0.035” to 0.500” / Custom | Standard, Random, Double Random, Custom Cut Length |
| Standard | Equivalent Grade |
|---|---|
| ASTM / ASME | ASME SA213 T92 |
| ASTM | A335 P92 |
| EN | EN 10216-2 X10CrWMoVNb9-2 |
| DIN | DIN 17175 14MoV63-2 |
| JIS | JIS G3462 T92 |
ASTM A213 T92 Tubes are used in high-temperature and high-pressure applications such as boilers, superheaters, reheaters, and heat exchangers. They are widely applied in power plants, petrochemical industries, and refineries.
T92 is a high-performance chromium-molybdenum-vanadium alloy steel grade with ~9% chromium, 0.5–1% molybdenum, and small additions of vanadium, niobium, and nitrogen. It provides superior creep strength and oxidation resistance at elevated temperatures.
Yes, ASTM A213 T92 Tubes are primarily manufactured in seamless (SMLS) form to ensure strength and reliability under high-temperature, high-pressure conditions.
T92 tubes are supplied in normalized and tempered condition to enhance mechanical properties, creep resistance, and toughness for high-temperature service.
Metal Tubular Products is a global stockist and supplier of ASTM A213 T92 Tubes, offering a wide size range, international certifications, and timely delivery for industrial, power generation, and petrochemical projects.
